Blowing Film Line Making Machine

分類: HDPE/ LDPE Plastic Bag Production Line

佛大工業股份有限公司

國家: 台灣

電話: 886-5-2215139 /886-5-2215149

傳真: 886-5-2219259

聯絡人: 李小姐

馬上詢問

The machine is applied to manufacture HDPE, LDPE, LLDPE plastic film, which is widely used in packaging film, agricultural covering film, textile packing, garment bag, shopping bag, plastic bag, garbage bag, and other packing area.

Film width is available from 150 mm~1200 mm depending on the customer’s request.
The main motor adopts inverter speed control to ensure the stability of performance and greatly save 30% of total power.
The traction frame adopts lifting type to give the best cooling quality whatever big and small size.
Screw and barrel are nitrided and hard chrome plated to ensure the best hardness and corrosion resistance giving the durable quality and long-term life.
Optional rotary die with 360° oscillation ensures smooth film surface and free of any gauge band.

Model	FD-HDE 45	FD-HDE 55	FD-HDE 65
Resin	HDPE/LDPE/LLDPE (FOR PLASTIC FILM GRADE)	HDPE/LDPE/LLDPE (FOR PLASTIC FILM GRADE)	HDPE/LDPE/LLDPE (FOR PLASTIC FILM GRADE)
Screw Diameter	45 mm	55 mm	65 mm
Extrusion Capacity	HDPE: 30-55 kg/hr / LDPE/LLDPE: 30~60 kg/hr	HDPE: 50~80 kg/hr / LDPE/LLDPE: 50~90 kg/hr	HDPE: 90~100 kgs/hr / LDPE/LLDPE: 90~110 kg/hr
Film Thickness	HDPE: 0.008MM-0.10 mm / LDPE/LLDPE: 0.01-0.20 mm	HDPE: 0.008~0.1 mm / LDPE/LLDPE: 0.01~0.2 mm	HDPE: 0.008-0.15 mm / LDPE/LLDPE: 0.01-0.20 mm
Film Width	150~660 mm	400~900 mm	800~1200 mm

HDPE Die: 1 Set
LDPE Die: 1 Set
HDPE Air Ring: 1 Set
LDPE Air Ring: 1 Set
