PLA擠出片材擠出機

PLA

0.2-1.2 mm

350 mm(MIN.)-600 mm (MAX.)

120-150 kg/hr

Before stretch: 1.0-10 m/min; after stretch: 60 m/min

75mm dia. L/D=32:1

75 HP A.C. inverter motor

FKI made

vertical type

φ 350 M/M dia. x 900 M/M  x 3

3 HP A.C. inverter for middle roller

2 HP A.C. inverter for upper & lower roller

1.0 – 10.0 m/min

φ 600 mm (MAX.)
